Mô tả sản phẩm
| Feature | ASRock USB 3.2 Gen2 |
| - ASRock Front Panel Type C USB 3.2 Gen2x2 Header (20 Gb/s) | |
| - ASRock USB 3.2 Gen2 Type-A Port (10 Gb/s) | |
| - ASRock USB 3.2 Gen2 Type-C Port (10 Gb/s) | |
| ASRock Super Alloy | |
| - XXL Aluminum Alloy Heatsink | |
| - Premium 60A Power Choke | |
| - 50A Dr.MOS | |
| - Nichicon 12K Black Caps (100% Japan made high quality conductive polymer capacitors) | |
| - I/O Armor | |
| - Matte Black PCB | |
| - High Density Glass Fabric PCB | |
| - 2oz Copper PCB | |
| 2.5G LAN 802.11ax Wi-Fi 6E | |
| ASRock Auto Driver Installer | |
| ASRock Steel Slot | |
| ASRock Full Coverage M.2 Heatsink | |
| ASRock Hyper M.2 (PCIe Gen4x4) | |
| ASRock Ultra USB Power | |
| ASRock POST Status Checker (PSC) | |
| ASRock Full Spike Protection (for all USB, Audio, LAN Ports) | |
| ASRock Live Update & APP Shop | |
| CPU | - Supports 12th Gen Intel® Core™ Processors (LGA1700) |
| - Digi Power design | |
| - 13 Power Phase design | |
| - Supports Intel® Hybrid Technology | |
| - Supports Intel® Turbo Boost Max 3.0 Technology | |
| Chipset | Intel® Z690 |
| Memory | - Dual Channel DDR4 Memory Technology |
| - 4 x DDR4 DIMM Slots | |
| - Supports DDR4 non-ECC, un-buffered memory up to 5000+(OC)* | |
| - Supports ECC UDIMM memory modules (operate in non-ECC mode) | |
| - Max. capacity of system memory: 128GB | |
| - Supports Intel® Extreme Memory Profile (XMP) 2.0 | |
| - 15μ Gold Contact in DIMM Slots | |
| BIOS | - 256Mb AMI UEFI Legal BIOS with multilingual GUI support |
| - ACPI 6.0 Compliant wake up events | |
| - SMBIOS 2.7 Support | |
| - CPU Core/Cache, CPU GT, DRAM, VCCIN AUX, +1.05V PROC, +1.8V PROC, +0.82V PCH, +1.05V PCH Voltage Multi-adjustment | |
| Graphics | - Intel® Xe Graphics Architecture (Gen 12) |
| - Dual graphics output: support HDMI and DisplayPort 1.4 ports by independent display controllers | |
| - Supports HDMI 2.1 TMDS Compatible with max. resolution up to 4K x 2K (4096x2160) @ 60Hz | |
| - Supports DisplayPort 1.4 with DSC (compressed) max. resolution up to 8K (7680x4320) @ 60Hz / 5K (5120x3200) @ 120Hz | |
| - Supports HDCP 2.3 with HDMI 2.1 TMDS Compatible and DisplayPort 1.4 Ports | |
| Audio | - 7.1 CH HD Audio (Realtek ALC897 Audio Codec) |
| - Supports Surge Protection | |
| - Gold Audio Jacks | |
| - 15μ Gold Audio Connector | |
| - Nahimic Audio | |
| LAN | - 2.5 Gigabit LAN 10/100/1000/2500 Mb/s |
| - Dragon RTL8125BG | |
| - Supports Dragon 2.5G LAN Software | |
| - Smart Auto Adjust Bandwidth Control | |
| - Visual User Friendly UI | |
| - Visual Network Usage Statistics | |
| - Optimized Default Setting for Game, Browser, and Streaming Modes | |
| - User Customized Priority Control | |
| - Supports Wake-On-LAN | |
| - Supports Lightning/ESD Protection | |
| - Supports Energy Efficient Ethernet 802.3az | |
| - Supports PXE | |
| Wireless LAN | - 802.11ax Wi-Fi 6E Module |
| - Supports IEEE 802.11a/b/g/n/ax | |
| - Supports Dual-Band 2x2 160MHz with extended 6GHz band support* | |
| - 2 antennas to support 2 (Transmit) x 2 (Receive) persity technology | |
| - Supports Bluetooth + High speed class II | |
| - Supports MU-MIMO | |
| Slots | - 3 x PCIe x16 Slots (PCIE2/PCIE3/PCIE5: single at Gen5x16 (PCIE2); dual at Gen5x16 (PCIE2) / Gen4x4 (PCIE3); triple at Gen5x16 (PCIE2) / Gen4x4 (PCIE3) / Gen3x4 (PCIE5))* |
| - 2 x PCIe Gen3x1 Slots | |
| - Supports AMD Quad CrossFireX™ and CrossFireX™ | |
| - 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module and Intel® CNVi (Integrated WiFi/BT) | |
| - 15μ Gold Contact in VGA PCIe Slot (PCIE2) | |
| Storage | - 8 x SATA3 6.0 Gb/s Connectors* |
| - 1 x Hyper M.2 Socket (M2_1, Key M), supports type 2260/2280 PCIe Gen4x4 (64 Gb/s) mode** | |
| - 1 x Ultra M.2 Socket (M2_2, Key M), supports type 2230/2242/2260/2280 SATA3 6.0 Gb/s & PCIe Gen3x4 (32 Gb/s) modes** | |
| - 1 x Hyper M.2 Socket (M2_3, Key M), supports type 2242/2260/2280/22110 PCIe Gen4x4 (64 Gb/s) mode** | |
| RAID | - Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices |
| - Supports RAID 0, RAID 1 and RAID 5 for M.2 NVMe storage devices | |
| Connector | - 1 x SPI TPM Header |
| - 1 x Power LED and Speaker Header | |
| - 1 x RGB LED Header* | |
| - 3 x Addressable LED Headers** | |
| - 1 x CPU Fan Connector (4-pin)*** | |
| - 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)**** | |
| - 5 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)***** | |
| - 1 x 24 pin ATX Power Connector (Hi-Density Power Connector) | |
| - 2 x 8 pin 12V Power Connectors (Hi-Density Power Connector) | |
| - 1 x Front Panel Audio Connector (15μ Gold Audio Connector) | |
| - 1 x Thunderbolt™ AIC Connector (5-pin) (Supports ASRock Thunderbolt™ 4 AIC Card) | |
| - 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection) | |
| - 2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports) (ASMedia ASM1074 hub) (Supports ESD Protection) | |
| - 1 x Front Panel Type C USB 3.2 Gen2x2 Header (20 Gb/s) (Supports ESD Protection) | |
| Rear Panel I/O | - 2 x Antenna Ports |
| - 1 x PS/2 Mouse/Keyboard Port | |
| - 1 x HDMI Port | |
| - 1 x DisplayPort 1.4 | |
| - 1 x Optical SPDIF Out Port | |
| - 1 x USB 3.2 Gen2 Type-A Port (10 Gb/s) (ReDriver) (Supports ESD Protection) | |
| - 1 x USB 3.2 Gen2 Type-C Port (10 Gb/s) (ReDriver) (Supports ESD Protection) | |
| - 4 x USB 3.2 Gen1 Ports (Supports ESD Protection) | |
| - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) | |
| - 1 x BIOS Flashback Button | |
| - HD Audio Jacks: Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone (Gold Audio Jacks) | |
| Software and UEFI | Software |
| - ASRock Motherboard Utility (A-Tuning) | |
| - ASRock Dragon 2.5G LAN Software | |
| - ASRock Polychrome SYNC* | |
| UEFI | |
| - ASRock EZ Mode | |
| - ASRock Full HD UEFI | |
| - ASRock My Favorites in UEFI | |
| - ASRock Auto Driver Installer | |
| - ASRock Instant Flash | |
| - ASRock Internet Flash | |
| - ASRock Easy RAID Installer | |
| Support CD | Drivers, Utilities, AntiVirus Software (Trial Version), Google Chrome Browser and Toolbar |
| Accessories | - Quick Installation Guide, Support CD |
| - 2 x SATA Data Cables | |
| - 1 x ASRock WiFi 2.4/5/6 GHz Antenna | |
| - 3 x Screws for M.2 Sockets | |
| - 2 x Standoffs for M.2 Sockets | |
| - 1 x Graphics Card Holder | |
| Hardware Monitor | - Fan Tachometer: CPU, CPU/Water Pump, Chassis/Water Pump Fans |
| - Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, CPU/Water Pump, Chassis/Water Pump Fans | |
| - Fan Multi-Speed Control: CPU, CPU/Water Pump, Chassis/Water Pump Fans | |
| - Voltage monitoring: CPU Vcore, PCH, DRAM, VCCIN AUX, +1.05V PROC, VCCSA, +1.8V PROC, +0.82V PCH, +12V, +5V, +3.3V | |
| Form Factor | - ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm |
| - 2oz Copper PCB | |
| OS | Microsoft® Windows® 10 64-bit / 11 64-bit |
| Certifications | - FCC, CE |
| - ErP/EuP ready (ErP/EuP ready power supply is required) | |
| - CEC Tier II ready |
